주요설비현황

HYDRAULIC PRESS BRAKE M/C
A동
장비 상세
제조사 ILWOO
Model IHUB 10060
Capacity 6T 3000mm 380V
Motor 11kW 4P
HYDRAULIC SHEAR M/C
A동
장비 상세
제조사 ILWOO
Model IHS10060
Capacity 6T 3100mm 380V
Motor 15kW 4P
CRANE 5톤
A동
CRANE 2.8톤
B동
CRANE 2.8톤
C동
CRANE 2.8톤
FA동
5축 가공기
C동
장비 상세
Model DMU60T
X,Y,Z Travel 630,560,560mm
Table Length/Width 1000/600mm
Table Load 400Kg
Feed rate X,Y,Z-Axis 26000,26000,20000mm
Spindle Taper 40/63 ISO/Bt/Mk
Power on spindle 13kW
Speed/ranges 18000rpm
수평형 바란싱머신(조인트 타입)
C동
장비 상세
제조사 제이앤에이치
Model JRH-300J
최대제품중량 300Kg
최대제품외경 Ø1200
축간거리 1500mm
축경범위 Ø15~75, Ø75~180mm
회전속도 ~1300+가변속 Rpm
모터파워 3.0kW(380V,60Hz)
Torque 60N.m
허용불균일도 1 g·mm/Kg
연마기
C동
장비 상세
제조사 PROTH
Model PSGO-75150AHR
Capacity Max. travel
(cross x longitudinal)
810X1650mm
Max. travel
(cross x longitudinal)
700mm
Grinding surface of table 750x1500mm
Longitudinal
Movement
Hydraulic table speed 1~25m/min

Cross
Movement

Intermittent cross feed-approx.(Electro-mechanical) 0.1-15mm/feed
Continuous cross feed-approx.(Electro-mechanical) 2000mm/min(50Hz),
2400mm/min(60Hz)
Hand feed per revolution 5mm
Hand feed per division 0.02mm
Vertical
Downfeed
Rapid traverse approx. 240mm/min
Hand feed per revolution 0.25mm
Hand feed per division 0.0025mm
Grinding
Wheel
Dimension(O.D x W x I.D) 355x50x127mm
Spindle speed(50/60Hz) 1500/1800 r.p.m.
Motor Spindle motor 7.5(11)kW/10(15)HP
Hydraulic motor 5.6kW/7.5HP
Weight Net weight 11000kg
Gross weight 12300kg
범용밀링 (2대)
C동
범용선반
C동
